Personal

	4Sevens Quark MiNi 123 (R5) Output (regulated): 189 / 40 / 3 OTF lumens Duration: 1.2 / 8 / 150 hr Primary Modes: low, medium, high Secondary Modes: strobe, SOS, low beacon, high beacon Emitter: white Cree 7090 XP-G R5 LED Voltage Range: 0.9-4.2V Bezel: twist for off/on, fast twist for low/medium/high Body: T-6061 aluminum Finish: black Type III hard anodized Lens: optical-grade glass with anti-reflective coating Waterproofing: resistant Length: 58mm (2.3") Diameter: 20mm (0.80") Weight: 18g (0.62oz) w/o battery Batteries: one 123
	4Sevens Quark AA (R5) Output (regulated): R14500: 229 / 85 / 22 / 4 / 0.2 OTF lumens AA: 109 / 85 / 22 / 4 / 0.2 OTF lumens Duration: R14500: 0.8 / 2.7 / 13 / 60 / 360 hr AA: 1.2 / 1.5 / 6 / 48 / 240 hr Modes: moonlight, low, medium, high, max, SOS, beacon, strobe Emitter: white Cree 7090 XP-E R5 LED Voltage Range: 0.9-4.2V Bezel: twist for general/max mode Button: push for off/on, soft-push for level Body: T-6061 aluminum Finish: black Type III hard anodized Lens: impact-resistant glass with sapphire coating Waterproofing: IPX-8 Length: 97mm (3.8") Diameter: 22mm (0.86") Weight: 51g (1.8oz) w/battery Batteries: one AA (or R14500)
	4Sevens Quark Prism Attaches to any full-sized Quark to bend the light path Angle: 90° Body: Rubber Size: 34×28×25mm (1.3×1.1×1.0")
	Streamlight Nano Output: 10 emitter lumens Duration: 8 hr Emitter: white 5mm LED Bezel: twist for off/on Body: aluminum Finish: black hard anodized Length: 37mm (1.47") Diameter (head): 13mm (0.51") Diameter (body): 11mm (0.43") Weight: 10g (0.36oz) w/battery Batteries: four LR41 alkaline
	Photon Freedom Duration: 12 hr (longer on lower settings) Emitter: white Nichia LED Button: push for mode selection (brightness/flashing) Body: fiberglass reinforced polyurethane Finish: black Size: 38×23×10mm (1.5"×0.9"×0.4") Weight: 6g (0.2oz) Batteries: two CR2016 lithium

Home and Vehicles

	Surefire Z2 CombatLight (modified) Output: 270 emitter lumens (regulated) Duration: 1.5 hr Emitter: white Cree 7090 XR-E Q5 LED Bezel: twist for off/on Button: push for momentary on Body: aluminum Finish: black anodized Length: 130mm (5.1") Diameter: 32mm (1.25") Weight: 136g (4.8oz) w/batteries Batteries: two CR123A lithiums
	Fenix P3D (Q5) Output: 215 / 120 / 53 / 12 emitter lumens (regulated) Duration: 1.8 / 4.8 / 13 / 65 hr Emitter: white Cree 7090 XR-E Q5 LED Bezel: twist for general/turbo mode Button: push for off/on, soft-push for level Body: aluminum Finish: natural hard anodized Length: 114mm (4.5") Diameter: 21mm (0.83") Weight: 48g (1.7oz) w/o battery Batteries: two CR123A lithiums
	4Sevens Quark 123 (R5) Output (regulated): 206 / 85 / 22 / 4 / 0.2 OTF lumens Duration: 0.8 / 2.7 / 13 / 60 / 360 hr Modes: moonlight, low, medium, high, max, SOS, beacon, strobe Emitter: white Cree 7090 XP-E R5 LED Voltage Range: 0.9-4.2V Bezel: twist for general/max mode Button: push for off/on, soft-push for level Body: T-6061 aluminum Finish: black Type III hard anodized Lens: impact-resistant glass with sapphire coating Waterproofing: IPX-8 Length: 81mm (3.2") Diameter: 22mm (0.86") Weight: 40g (1.4oz) w/battery Batteries: one 123
	Pila GL3 (modified) LEDs Upgraded by Scott Clawson (email to scott(at)release1(dot)com) Output: 200 / 15 emitter lumens Duration: 20 min / 50 hr Emitter: Pila 9V xenon bulb and 4 white 5mm Nichia LEDs Bezel: twist for off/low/high Button: push for momentary high Body: aluminum Finish: black anodized Length: 165mm (6.5") Diameter: 36mm (1.4") Weight: 190g (6.7oz) w/o batteries Batteries: three CR123A lithiums
	4Sevens Quark AA (R2) Output (regulated): R14500: 189 / 70 / 18 / 3.5 / 0.2 OTF lumens AA: 90 / 70 / 18 / 3.5 / 0.2 OTF lumens Duration: R14500: 0.8 / 2.7 / 13 / 60 / 360 hr AA: 1.2 / 1.5 / 6 / 48 / 240 hr Modes: moonlight, low, medium, high, max, SOS, beacon, strobe Emitter: white Cree 7090 XP-E R2 LED Voltage Range: 0.9-4.2V Bezel: twist for general/max mode Button: push for off/on, soft-push for level Body: T-6061 aluminum Finish: black Type III hard anodized Lens: impact-resistant glass with sapphire coating Waterproofing: IPX-8 Length: 97mm (3.8") Diameter: 22mm (0.86") Weight: 51g (1.8oz) w/battery Batteries: one AA (or R14500)
	NiteCore D10 (R2) Output: 145 to 3 OTF lumens (regulated) Duration: AA: 50 min to 45 hr R14500: 80 min to 60 hr Emitter: white Cree 7090 XR-E R2 WC LED Bezel: twist for off/on Button: push for off/on and brightness (SmartPD piston drive) Body: 7075 aluminum Finish: black Type III hard anodized Length: 89mm (3.5") Diameter: 19mm (0.75") Weight: 40g (1.4oz) w/o battery Batteries: one AA (or R14500)
	Fenix L2D (Q5) Output: 180 / 107 / 53 / 12 emitter lumens (regulated) Duration: 2.4 / 4 / 10.5 / 55 hr Emitter: white Cree 7090 XR-E Q5 LED Bezel: twist for general/turbo mode Button: push for off/on, soft-push for level Body: aluminum Finish: olive green hard anodized Length: 147mm (5.8") Diameter: 21mm (0.83") Weight: 57g (2.0oz) w/o battery Batteries: two AA
	Fenix P2D (Q5) Output: 180 / 107 / 53 / 12 emitter lumens (regulated) Duration: 1 / 2 / 5.5 / 30 hr Emitter: white Cree 7090 XR-E Q5 LED Bezel: twist for general/turbo mode Button: push for off/on, soft-push for level Body: aluminum Finish: olive green hard anodized Length: 78mm (3.1") Diameter: 21mm (0.83") Weight: 37g (1.3oz) w/o battery Batteries: two CR123A lithiums
	Fenix P1D (Q5) Output: 180 / 96 / 16 emitter lumens (regulated) Duration: 1 / 2.8 / 21 hr Emitter: white Cree 7090 XR-E Q5 LED Bezel: twist for off/on, fast twist for medium/low/high/Strobe/SOS Body: aluminum Finish: olive green hard anodized Length: 71mm (2.8") Diameter: 21mm (0.83") Weight: 28g (1.0oz) w/o battery Batteries: one CR123A lithium
	NiteCore EX10 (Q5) Output: 130 to 3 OTF lumens (regulated) Duration: CR123A: 110 min to 65 hr RCR123A: 80 min to 60 hr Emitter: white Cree 7090 XR-E Q5 WC LED Bezel: twist for off/on Button: push for off/on and brightness (SmartPD piston drive) Body: 7075 aluminum Finish: black Type III hard anodized Length: 77mm (3.0") Diameter: 21.5mm (0.85") Weight: 35g (1.2oz) w/o battery Batteries: one CR123A (or RCR123A) lithium
	NiteCore EZ AA (Q5) Output: 130 / 15 OTF lumens (regulated) Duration: 1.5 / 20 hr Emitter: white Cree 7090 XR-E LED Bezel: twist for off/low/high Body: aluminum Finish: black Type III hard anodized Length: 83mm (3.3") Diameter: 16.6mm (0.65") Weight: 20g (0.7oz) w/o battery Batteries: one AA (max 2V)
	Surefire G2 Nitrolon Output: 120 OTF lumens Duration: 20 min Emitter: Surefire P61 xenon bulb Button: push for momentary Bezel: twist for off/on Body: Nitrolon polymer Finish: black Length: 124mm (4.9") Diameter: 32mm (1.25") Weight: 116g (4.1oz) w/batteries Batteries: two CR123A lithiums
	Maratac AAA (Q5) Made by ITP based on the A3 EOS Upgrade Edition Output: 62 / 18 / 1.5 OTF lumens (regulated) Duration: 0.8 / 4 / 50 hr Emitter: white Cree 7090 XR-E Q5 LED Bezel: twist for off/on, fast twist for medium/low/high Body: aluminum Finish: natural Type III hard anodized Length: 66.5mm (2.6") Diameter: 14mm (0.5") Weight: 9g (0.3oz) w/o battery Batteries: one AAA
	Fenix LD01 (Q5) Output: 80 / 27 / 10 emitter lumens (regulated) Duration: 1 / 3.5 / 8.5 hr Emitter: white Cree 7090 XR-E Q5 LED Bezel: twist for off/on, fast twist for medium/low/high Body: aluminum Finish: black Type III hard anodized Length: 74mm (2.9") Diameter: 15mm (0.6") Weight: 14g (0.5oz) w/o battery Batteries: one AAA
	Fenix E01 Output: 10 emitter lumens (regulated) Duration: 21 hr Emitter: white Nichia GS LED Bezel: twist for off/on Body: aluminum Finish: blue Type III hard anodized Length: 71mm (2.8") Diameter: 15mm (0.6") Weight: 14g (0.5oz) w/o battery Batteries: one AAA
	Arc Flashlight Arc-AAA Premium Output: 5.5 OTF lumens (regulated) Duration: 9 hr Emitter: white 5mm Nichia CS LED Bezel: twist for off/on Body: aluminum Finish: natural Type III hard anodized Length: 69mm (2.7") Diameter: 13mm (0.5") Weight: 21g (0.75oz) w/battery Batteries: one AAA
	Princeton Tec Aurora Duration: 50 / 110 / 160 hr Emitter: 3 white 5mm LEDs Button: push for mode selection (low/medium/high/fast/slow) Body: plastic Finish: blue Headband: 25mm (1") elastic single-loop Size: 57×44×25mm (2.25"×1.75"×1") Weight: 79g (2.8oz) w/batteries Batteries: three AAA

OTF (out-the-front) lumen ratings represent the amount of light that is actually leaving the device. Emitter luman ratings represent the amount of light that is theoretically being generated at the emitter before losses to the optics and the reflector. To accurately compare the two types of ratings reduce emitter lumens by 30% to 40%.

---
